3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0

3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0
Roll over image to Zoom
3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0
SKU:
600-volts-wire-and-cables

Select a Gauge

3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0
Min Length: 1 FT
Max Length: 10000 FT
Price:
Regular price
$0.00 /FT
Sale price
$0.00 /FT
Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.
Free Shipping: On orders above $1000
Quantity must be 1 or more

Enter the required footage in the quantity box - Cut to one length

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Where are we? 4 Continents 9 Countries

map
garrie

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Product Information
Specification

3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0

Allowable Ampacity for 3/0 AWG 1672/30 Stranded Nickel Coated Copper PTFE 260°C 600V Aerospace Cable M25038/1-3/0100 Amps

Applications:

• Critical circuit aerospace applications where wires must operate in extremely harsh environments, under vibration, and maintain electrical integrity for a short time under direct flame exposure during emergency conditions

Also Known as :

M25038/1 Cable, Military Wire, High-Temperature Wire, Polyester Braid Cable, Silver Coated Cable, Mil-Spec cable, Aircraft Cable

Description :

 22 - 20 AWG: 27% nickel-coated high-strength copper alloy
 18 - 12 AWG: 27% nickel-coated copper
 Inner insulation: Inorganic dielectric
 Outer insulation: PTFE-coated fiberglass barrier
 Operating temperature: -55°C to +260°C
 Voltage rating: 600 volts
 Type: JA

Specification :

• AWG: 3/0
• Stranding: 1672/30
• Nom. Diameter of Conductor: 0.520 inches
• Nom. O.D: 0.680 inches
 Weight: 0.6804 lbs
 Part Number: M25038/1-3/0


*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
