Belden 83267 30 AWG 1 Conductor 7x38 Stranding RG-187 75 Ohm Coax Cable

Name: Belden 83267 30 AWG 1 Conductor 7x38 Stranding RG-187 75 Ohm Coax Cable
Brand: Belden Cable
SKU: NNC83267
Price: 4.88 USD
Availability: InStock
Rating: 4.91 (8335 reviews)

Roll over image to Zoom

Write a Review

Ask a Question Download PDF Buyer Guide

SKU: NNC83267

Select a Gauge

Belden 83267 30 AWG 1 Conductor 7x38 Stranding RG-187 75 Ohm Coax Cable

Availability: In stock

Min Length: 1 FT

Max Length: 10000 FT

Price:

Regular price: $7.28
Sale price: $4.88 /FT 32% off

Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.

Free Shipping: On orders above $1000

Length (FT):

Enter the required footage in the quantity box - Cut to one length

Where are we? 4 Continents 9 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Information

Specification

Belden 83267 30 AWG 1 Conductor 7x38 Stranding RG-187 75 Ohm Coax Cable

Description:

75 ohm, 30 AWG stranded (7x38) 0.012" silver-plated copper-covered steel conductor, TFE Teflon insulation, silver-plated copper braid shield (95% coverage), TFE tape jacket.

Insulation:

• Material: PTFE - Polytetrafluoroethylene
• Material Trade Name: Teflon
• Nominal Diameter: 0.063 in

Outer Shield:

• Outer Shield Type: Braid
• Material: Silvered Copper (SC)
• Coverage: 95%

Outer Jacket:

• Material: PTFE - Polytetrafluoroethylene
• Material Trade Name: Teflon
• Nom. Diameter: 0.105 in

Specifications:

• Size (AWG): 30
• Conductor Count: 1
• Stranding: 7x38
• Nom. Diameter: 0.012 in
• Impedance: 75 Ohm
• RG Type: 187
• Conductor Material: SCCS - Silvered Copper Covered Steel
• Part Number: 83267

Manufacturer Equivalents
Alpha Wire :	White : 9187A
Anixter :	White : B83267
Belden :	White : 83267 0091000
Wirexpress :	White : B83267
