Blue Sea Battery Switches HD-Series Dual Circuit

Product Information

Specification

Blue Sea Battery Switches HD-Series Dual Circuit

Also Known As:

Dual Circuit, Battery Switches, HD-Series, Battery Switches, Blue Sea

About:

Battery switches are designed with safety in mind. They protect your electrical system by preventing the spread of flame during a fire. They do this by isolating the battery. The ABYC requires that all boats with 800 cranking amps or more have a battery switch installed. The HD-Series are rated for up to 600 Amps continuous for large diesel engines. They carry a durable case and have been designed with the harshest marine conditions in mind. This makes them perfectly suited for use in marine applications where exposure is a concern. Selecting the correct part is not an easy task.

Construction:

• Accepts up to 4/0 AWG battery cable
• Studs accept 1/2" (M12) ring terminals
• 7/8" (22 mm) Stud length accepts multiple cable terminals
• Tin-plated copper studs for maximum conductivity and corrosion resistance

Strands:

• CE
• IP 66
• ISO 8846
• SAE J1171
• ABYC E-11
• UL 1077, UL 1500

Features:

• Advanced Multi Stage Charging
• Built In Safety Features
• Durable Aluminum Case
• One-time terminal stud design never loosens over time
• Tactile indicator conveys knob position by feel
• Case design allows surface, rear, or front panel mounting options
• Fits most Perko and Guest low amperage battery switch hole patterns

Specifications:

• Switch Positions : 2 - 4
• Color : Grey
• Maximum Voltage : 32 V DC
• Continuous Rating : EBS-3000 = 600 A / EBS-3002 = 500 A
• Intermittent Rating : EBS-3000 =900 A (5 min) / EBS-3002 = 700 A (5 min)
• Battery Inputs : EBS-3000 = 1 / EBS-3002 = 2
• Dimensions : W=2.82", H=2.82", D=3.07"
• Part Number: EBS
