2" Meters Fiber Optic Jumper 1 F LC to SC Tight Buffered Cable Riser 2.0 mm Standard LCUPC Simplex SM Standard SCUPC Simplex SM SMF Ultra 1F Single Fiber Riser Standard Yellow Jacket 025801G2131002M

Product Information

Specification

About:

Simplex cable assemblies are offered with a variety of connector combinations. Connector options include LC, SC, FC and ST Compatible. RoHS compliant cables with riser-rated jackets are available in 3.0 mm, 2.0 mm, 1.6 mm and 900 µm.

Specifications:

Flame Rating: Riser (OFNR)
Fiber Category: Bend-improved Single-Mode (OS2)
Cable Assembly Type: Single fiber
Cable Type: Tight-Buffered
Fiber Count: 1
Outer Jacket Color: Yellow
Fiber Code: G
Fiber Type: Single-Mode Ultra-Bendable Fiber
Fiber Core Diameter: 8.2 µm
Maximum Attenuation: 0.4 dB/km / 0.4 dB/km / 0.3 dB/km
Serial 1 Gigabit Ethernet: 5000 MHz*km / - / -
Serial 10 Gigabit Ethernet: 10000 MHz*km / - / 40000 MHz*km
Wavelengths: 1310 nm / 1383 nm / 1550 nm
Fiber Category: OS2
Polish: UPC
Insertion Loss, Typical: 0.15 dB
Boot Color: Blue
Connector A Type: LC
Connector B Type: SC
Ferrule Material: Ceramic
Housing Color: Blue
Housing Material: Composite
Part Number: 025801G2131002M

Features:

• Flame-retardant jacket
Rugged and durable
• Superior Performance Testing
Every termination is tested to ensure the highest in network performance
• State-Of-The-Art Manufacturing Processes
Corning proprietary manufacturing processes and advanced technology result in unsurpassed product consistency
• Corning advantage
Integrated developer and manufacturer of cable, connectors and fiber to ensure overall cable assembly performance
