XHHW-2 COPPER BUILDING WIRE CONDUCTOR

Name: XHHW-2 COPPER BUILDING WIRE CONDUCTOR
Brand: Nassau National Cable
SKU: NNC3174X
Availability: InStock
Rating: 4.93 (7819 reviews)

Roll over image to Zoom

Write a Review

Ask a Question Download PDF

SKU: NNC3174X

Select a Gauge

XHHW-2 COPPER BUILDING WIRE CONDUCTOR

Where are we? 4 Continents 8 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Name	Length	Price (Per FT.)	Action
Product Name 14 XHHW-2 Solid Copper Building Wire	Length /FT	Price (Per FT.) $0.26 Available Min: 150 FT Max: 1000000 FT	Action Color
Product Name 12 XHHW-2 Solid Copper Building Wire	Length /FT	Price (Per FT.) $0.40 Available Min: 120 FT Max: 1000000 FT	Action Color
Product Name 10 XHHW-2 Solid Copper Building Wire	Length /FT	Price (Per FT.) $0.49 Available Min: 100 FT Max: 1000000 FT	Action Color
Product Name 14 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $0.29 Available Min: 150 FT Max: 1000000 FT	Action Color
Product Name 12 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $0.40 Available Min: 120 FT Max: 1000000 FT	Action Color
Product Name 10 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $0.54 Available	Action Color
Product Name 8 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $0.84 Available	Action Color
Product Name 6 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $1.10 Available	Action Color
Product Name 4 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $1.69 Available	Action Color
Product Name 3 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $2.14 Available	Action Color
Product Name 2 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $2.69 Available	Action Color
Product Name 1 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $3.29 Available	Action Color
Product Name 1/0 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $4.19 Available	Action Color
Product Name 2/0 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $5.19 Available	Action Color
Product Name 3/0 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $6.36 Available	Action Color
Product Name 4/0 XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $7.49 Available	Action Color
Product Name 250 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $8.49 Available	Action Color
Product Name 300 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $10.09 Available	Action Color
Product Name 350 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $11.59 Available	Action Color
Product Name 400 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $12.99 Available	Action Color
Product Name 500 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $15.69 Available	Action Color
Product Name 600 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $20.29 Available	Action Color
Product Name 700 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock	Action
Product Name 750 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $29.22 Available	Action Color
Product Name 1000 MCM XHHW-2 Copper Building Wire	Length /FT	Price (Per FT.) $41.99 Available	Action Color

Product Information

Specification

XHHW-2 Copper Building Wire Conductor

Applications:

XHHW is a multi-purpose electrical wire with cross-linked high heat water-resistant insulation. The most common applications include raceways for branch circuit wiring, conduits, services, and feeders. It is also used as a building wire. XHHW is suitable for industrial applications due to its toughness and excellent resistance to chemicals. The electrical wire is suitable for temperatures up to 90°C, with a voltage rating of 600 volts.

Also Known As:

XHHW RW90 Copper Building Wire, XHHW Cable, XHHW Service Wire, XHHW Copper Wire.

Standards:

UL Standard 44
ASTM Standard B 3
Federal Specification A-A-59544
National Electrical Code
ICEA S-95-658 (NEMA WC 70) - Non Shielded 0 - 2 kV

Construction:

Conductor:

The cable has an annealed bare copper conductor (solid or concentrically stranded). The conductor has excellent electrical conductivity and excellent resistance to moisture. The conductor also has excellent resistance to compression, pressure, and heat.

Insulation:

The cable is insulated with a cross-linked polyethylene jacket (XLPE) that serves as a protective armor to the conductors. It is flame-retardant and resistant to abrasion, corrosion, moisture, dryness, chemicals, and heat.

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
