Indoor/Outdoor 48 Strand 2.5mm Breakout Series Multimode 62.5µm Black Fiber Optic Cable BX048DWLS9KR
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Tensile Load | Menimum Bend Radius | |||||||
| Diameter | Weight | Installation | Operational | Installation | Long Term | |||
| Fiber Count | Fiber Type | Part Number | mm/(in) | kg/km (lbs/1,000) | N (lbs) | N (lbs) | cm (in) | cm (in) |
| 48 | WLS - 62.5µm OM1 | BX048DWLS9KR | 24.2 (0.95) |
483.0 (325.0) |
18,000 (4,050) |
7,500 (1,690) |
36.3 (14.3) |
24.2 (9.5) |
APPLICATIONS:
• Fiber Optic tray Cable: Suitable for use in cable trays
• Ideal for installations requiring an extremely rugged and reliable cable design where maximum mechanical and environmental protection are necessary
• Easiest cable to install where direct termination of the subcable to a connector and a direct run to panels and equipment are desired
Cost Savings:
• Direct termination to subcable may eliminate the need for patch panels and patch cords and reduces connector loss
• 900 µm buffer eliminates the need for costly and time-consuming installation of fanout kits or pigtail splices because connectors terminate directly to the subcable
• High crush resistance may eliminate the need for innerduct
STANDARDS:
Optical Cable Corporation Indoor/Outdoor tight-buffered fiber optic cables meet the functional requirement of the following standards:
• UL 1651
• UL 1666
• GR-409-CORE
• ICEA-S-104-696
• ICEA-S-83-596
• TIA-568
• TIA-598
CHARACTERISTICS:
| Characteristic | 2.5mm subcables |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -55°C to +85°C |
| Install Temp | -10°C to +60°C |
| Flame Retardancy | UL Listed Type OFNR (UL 1666) and FT4 (CSA C22.2 No. 232) |
| Crush Resist | 2200 N/cm |
| Impact Resist | 1500 impacts |
| Flex Resist | 2000 cycles |
| Jacket Type | D |
FEATURES:
• High performance components and construction
• UL Listed in accordance with NEC sections 770.179(b) for use in vertical runs in building riser shafts or from floor to floor
• Most rugged and easy to install cable design for enterprise cabling applications
• Core-Locked™ outer jacket design for installation survivability and long-term, trouble free service
• Ideal for use in long, vertical installations
• 2.5mm subcables can be direct-terminated with standard connectors (2.0mm and 2.9mm subcables also available)
• Subcabled fiber is environmentally and mechanically protected
• Ideal for use in point-to-point runs in adverse environments
• Direct termination to subcable provides additional strain relief for better connector retention during moves, adds, and changes
• Design is ideal for direct pulling with mesh grips
• Cable materials are Indoor/Outdoor - UV, water and fungus resistant
• Wide operating temperature range of -40°C to +85°C
• High performance 900 µm tight-buffered coating on each optical fiber for environmental and mechanical protection
• Interlocking armor can be applied to cables as an alternative to conduit installation
• 2 to 72 fibers
Download PDF Spec Sheet
