Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable

Name: Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable
Brand: Belden Cable
SKU: NNC9272
Price: 3.4 USD
Availability: InStock
Rating: 4.91 (8357 reviews)

Roll over image to Zoom

Write a Review

Ask a Question Download PDF Buyer Guide

SKU: NNC9272

Select a Gauge

Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable

Availability: In stock

Min Length: 1 FT

Max Length: 10000 FT

Price:

Regular price: $3.40 /FT
Sale price: $3.40 /FT

Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.

Free Shipping: On orders above $1000

Length (FT):

Enter the required footage in the quantity box - Cut to one length

Where are we? 4 Continents 9 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Information

Specification

Belden 9272 20 AWG 2 Conductor 7x28 Stranding 78 Ohm Twinax Cable

Description:

78 Ohm Twinax, 20 AWG stranded (7x28) .038" tinned copper conductors, polyethylene insulation, tinned copper braid shield (93% Coverage), PVC jacket.

Insulation:

• Material: PE - Polyethylene
• Nominal Diameter: 0.0755 in

Outer Shield:

• Layer 1: Type Braid, Tinned Copper (TC) Material, Coverage [%] 93%

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.244 in

Specifications:

• Size (AWG): 20
• No. of Conductor: 2
• Stranding: 7x28
• Nom. Diameter: 0.038 in
• Impedance: 78 Ohm
• Conductor Material: TC - Tinned Copper
• Part Number: 9272
