Product Information
Specification

4/0-4/0-2/0-4 Aluminum Mobile Home Feeder Direct Burial Cable 600V

Allowable Ampacity for 4/0-4/0-2/0-4 Aluminum Mobile Home Feeder Cable: 200 Amps

Applications:

4/0-4/0-2/0-4 Aluminum Mobile Home Feeder Cable is a 200-amp, 600V-rated service entrance cable designed to supply power from a utility meter base to the main distribution panel in a mobile or manufactured home. It is also suitable as a high-capacity feeder cable for subpanels in modular buildings, large residential units, detached garages, shops, and light commercial installations.

This cable is approved for direct burial when marked USE-2 and may also be installed in conduits, ducts, or raceways in wet or dry locations. Its cross-linked polyethylene (XLP) insulation provides excellent durability and resistance to moisture, abrasion, and chemicals, making it ideal for underground and outdoor use.

In size 4/0-4/0-2/0-4, the cable is commonly used to deliver 200 amps of power to subpanels supporting multiple branch circuits, heavy-duty appliances, HVAC systems, and general-purpose loads in high-demand environments.

Also Known As:

4/0-4/0-2/0-4 aluminum cable, 4/0-4/0-2/0-4 aluminum wire, 4/0-4/0-2/0-4 mobile home feeder cable, 4/0-4/0-2/0-4 underground feeder cable, 4/0-4/0-2/0-4 service entrance cable, 4/0-4/0-2/0-4 electrical feeder cable, 4/0-4/0-2/0-4 power feeder cable, 4/0-4/0-2/0-4 MHF cable, 200 amp mobile home feeder wire, 4/0-4/0-2/0-4 direct burial wire.

Standards:

  • Ampacities based on National Electric Code, 2005n edition, section 310-15

  • National Electric Code (NEC)

  • UL 44 for types RHH & RHW-2

  • UL 854 for type USE-2

  • ASTM standards B 800, B 801

  • Sunlight resistant

  • RUS ACCEPTED

Construction

Conductors:

The 4/0-4/0-2/0-4 cable includes two 4/0 AWG phase conductors, one 2/0 AWG neutral, and one 4 AWG ground. All conductors are compact stranded 8000 series aluminum per ASTM B-800/B-801.

Insulation:

It has cross-linked polyethylene (XLP) insulation. The conductors are normally cabled together with XLP-insulated aluminum ground or bare copper ground and covered with reinforced binder tape. XLP insulation is tough and resistant to impact, abrasion, chemicals, acids, oils, industrial solvents, and changes in weather.

Specifications:

  • Cable Construction: 4/0-4/0-2/0-4

  • Phase Conductor; Insulation (mils): 80

  • Insul. Phase Conductor; Diameter (inches): 0.635

  • Insul. Grounded (Neutral) Conductor; Diameter Inches: 0.540

  • Insul. Equipment Grounding Conductor; Diameter Inches: 0.335

  • Cable Diameter Inches: 1.540

  • New Weight lb/1000FT: 778 lbs

  • Ampacity: 200 Amps

Compatible with Manufacturer

Priority Wire & Cable : 4/0-04ALUM-MHF-R
Houston Wire & Cable : HW023A40204
Southwire : 30161401
Omni Cable : MHF4/02C-2/0-4


*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Download PDF Spec Sheet
