UTP CAT5E Cable 305m DH-PFM920I-5EU-U
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Material | Oxygen free copper (99.97% purity) |
| Diameter | 0.50 mm ± 0.01 mm |
| American Wire Gauge | 24AWG |
| Material (Insulation) | HDPE |
| Min. Average Thickness | 0.18 mm |
| Material (Rip Cord) | Polyester |
| Specification | 500D |
| Max. DC Resistance of a Single Conductor | 9.38Ω/100 m |
| Min. Insulation Resistance | 5000MΩ·km |
| Max. DC Resistance Unbalance | 5% (pair intra) |
| Dielectric Strength | No breakdown with 2.5KV DC for 2 seconds |
| Max. Attenuation | 22.0 dB/100 m@100 MHz |
| Part No | DH-PFM920I-5EU-U |
UTP CAT5E Cable 305m DH-PFM920I-5EU-U
DESCRIPTION :
Network cables are the most commonly used transmission mediums in generic cabling system. It is usually composed of 4 pairs of twisted wires, and is generally applied in system cabling within 100 meters.
FEATURES :
⦿ 305 m (1000 ft)/carton UTP CAT5e, power over Ethernet, compatible with one cable
⦿ High-purity oxygen-free copper conductor material
⦿ Customized PVC outer sheath; ANSI UL CM flame retardant class certified
⦿ 10-year warranty
