Uniboot Jumper in a Box 50 µm multimode (OM4) 10 m CORNING 7979-OM4-B50-10M
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Cable Type | Tight-Buffered |
| Flame Rating | Riser (OFNR) |
| Cable Assembly Type | Two Fiber |
| Application | Data Center LAN/SAN, Enterprise Networks |
| Minimum Bend Radius | 10 mm (0.39 in) |
| Part Number | 7979-OM4-B50-10M |
Description:
Jumper in a box is an innovative packaging solution designed to fulfill your needs of the organization, convenience, and efficiency. It includes a self-tracking inventory system and bold, color-coded part identification at a glance. Jumpers are available in a wide range of configurations
Optical Characteristics:
| Fiber Code | Q |
| Fiber Type | Multimode |
| Fiber Compliance | IEC 60793-2-10 for A1a class 50/125 multimode fibers; TIA/EIA 492AAAD (OM4); ITU-T Recommendation G.651; ISO/IEC 11801 Ed.2.2 Grade OM4 |
| Fiber Core Diameter | 50 µm |
| Minimum Effective Modal Bandwidth (EMB) | 4700 MHz*km / - |
| Maximum Attenuation | 2.8 dB/km / 1.0 dB/km |
| Min. Overfilled Launch (OFL) Bandwidth | 1500 MHz*km / 500 MHz*km |
| Serial 1 Gigabit Ethernet | 1000 MHz*km / 600 MHz*km |
| Serial 10 Gigabit Ethernet | 600 MHz*km / - |
| Wavelengths | 850 nm / 1300 nm |
| Fiber Category | OM4 Extended Distance |
Connector A and Connector B:
| Boot Color | Aqua |
| Connector Type | LC Uniboot |
| Ferrule Material | Ceramic |
| Housing Color | Black |
| Housing Material | Composite |
Product Features:
• Bags that are connected with individual jumpers in an easy payout
• Easy inventory management and inventory control
• Compact box design that fits the same profile as copper cable boxes
• Fits alongside standard copper cable payout boxes, easy to store on shelves
• Easy to identify box labeling of jumper type/QR code
• Quick visual identification makes it easy to find the correct jumper very quickly, type and length
• Identifier that lets the customer know it is time to reorder
• Helps control inventory and reduces the risk of running out of product
• Reduced individual jumper packaging
• Less waste and less time to unpackage
• Sequential number of each jumper in the payout box
• Helps control inventory
• Re-sealable individual bags
• Can re-package and keep new LC uniboots safe even after the bag is opened and separated from the reel of bags and the box
Download PDF Spec Sheet
