SIP HD Video Emergency Phone with Enhanced Weather VIK-X-1605-EWP

Product Information

Specification

Viking X-1605-EWP SIP HD Video Emergency Phone with Enhanced Weather

About :

The X-1605-EWP IP Video Emergency Phone offers HD video and hands-free communication for SIP VoIP systems. It features a built-in H.264 IP camera with 1080p resolution, 126-degree wide-angle view, and low light sensitivity. The phone supports programmable dialing, remote configuration via Web UI, and includes a 2 Amp relay for door or gate control. Powered by PoE class 2, it has a red LED for call status and includes Enhanced Weather Protection (EWP) for outdoor use, meeting IP66 standards with sealed components and durable design for harsh environments.

Also Known As :

Emergency Phone, Emergency Call Box, Hotline Phone, Help Point Phone, Hotline Phone

Specification :

Core Features :

• SIP compliant
• ONVIF Profile S compliant
• 126° wide viewing angle
• H.264 and MJPEG video encoding
• Up to 1080p SIP video calling
• Separate NVR stream with audio up to 1080p
• Selectable video resolutions: 352 x 288, 704 x 526, 720p and 1080p
• Remotely programmable via Web UI
• 2 Amp relay contacts for door/gate or optional SL-2 strobe light
• Red backlit 316 stainless steel push button switch
• PoE powered (class 2, < 6.5 Watts)
• Network downloadable firmware
• T-10 Torx security screws for added security
• Handsfree operation
• Vandal resistant 16 gauge steel with a durable high-visibility red powder painted finish
• Includes Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 • Ingress Protection Rating
• Cycles through backup phone numbers on busy or no-answer
• Extended temperature range of -40° F to 140° F
• Volume adjustments for microphone and speaker
• Surface mount to walls, posts, single gang boxes or 4” x 4” electrical ­­­­­­­­­boxes
• Diagnostics for testing microphone, speaker, and relay
