About:

The "Profinet 681/682 Tinned/Bare Copper Al Tape TC Braid PUR Network Cable" is designed for industrial communication networks, particularly for Profinet applications.

Also Known As:

This type of cable may have specific model designations like "Profinet Type C Cable" or industry-specific names, but the exact alternate names can vary based on the manufacturer and regional standards.

Application:

• Industrial Ethernet Networks: Especially in Profinet systems, a prevalent standard in industrial automation for fast and secure data communication.
• Harsh Industrial Environments: Its robust construction makes it suitable for areas with high mechanical stress, oil exposure, and varying temperatures.
• Real-Time Automation and Control Systems: Ideal for applications requiring high data integrity and minimal latency.

Standards:

• Profinet Compliance: Specifically designed to meet Profinet communication protocols and standards.
• UL Certification: Likely to be UL certified, ensuring it meets specific safety and quality standards.
• Possibly compliant with other industrial standards depending on the manufacturer and region.

Construction:

• Conductor: (PROFINET 681): Flexible tinned copper conductors extra fine wires
(PROFINET 682): Flexible plain annealed copper conductors extra fine wires
• Insulation: Halogen free compound
• Colour cores: white/blue, white/orange, white/green, white/brown
• Stranding: Cores twisted in pairs
• Wrapping: Non-woven tape
• Screen: Aluminium tape and tinned copper braid
• Outer Sheath: Green (similar RAL 6018) PUR compound

Features:

• AWM 10493-20233 300V/80°C CE (SPECIAL PROFINET 682)
• acc. to standards: EN 50288-1, EN 50288-2-2, EN 50173, IEC 61156-3, ISO/IEC 11801 (SPECIAL PROFINET 682)
• For SPEED see pages from 2 to 4 of Automation and Flexidrum® catalogue
RoHS and CE approval

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
