Product Information
Specification
| Input voltage: | DC 10~34V |
| Output voltage: | DC 1~34V |
| Max. input current: | 60A |
| Charging current: | 0.2~30A x2 |
| Discharging current: | 0.2~3.0A x2 |
| Balance current: | 1.5A/Cell Max |
| Max. discharging power: | 30W x2 |
| Max. charging power: | Single channel Max. 1000W; Whole model Max. 1500W |
| Abnormal voltage alarm: | support |
| Incorrect cell count setting alarm: | support |
| Supported battery types and cell count: | LiFe, Lilon, LiPo 1~8S, LiHv 1-7S, Pb 1-12S, NiMH, Cd 1-16S |
| Output interface: | XT60i（XT60 compatible） |
| Input interface: | XT90i（XT90 compatible） |
| Display: | 3.5’’ 320×480 IPS LCD |
| Working temperature: | 0~40℃ |
| Storage temperature: | -20℃~60℃ |
| Dimension: | 110x110x65mm |
| Weight: | 730g |
High Power Dual Channel with Smart Charging, 3.5” High-Resolution IPS screen P30
Description:
• Smart High-Speed Processor delivers parameter interference to each port. Hassle-Free with Maximum charging power up to 1000W for a single port. Choose ISDT, Powered by Innovation.
• Built-in High-Speed Processor Synchronous Balance two-channel charging. Maximum Parallel Charging power up to 1500W. P30 delivers charging current range from 30A ~ 50A.
• Anodized Magnesium Alloy shell. Premium High Gloss Thin lines Finishing by edge’s Chamfer process. Unique Appearances with High Effective Heat Dissipation Design.
Features:
• High Power Dual Channel Input and Power Distribution
• Synchronous Parallel charging
• Aluminum Housing
• 3.5” High-Resolution IPS screen
• Sample Touch Swipe Interface
• OTA upgrade
