Lapp H07Z1-K Single Cable 4724086 1 x 16 Core and mm² Bare Copper Halogen Free Brown
Where are we? 4 Continents 9 Countries
Specification
-
Conductor cross-section (mm²): 16
-
Core colour: Brown
-
Outer diameter [mm]: 0.2637 - 0.3188 Inches
-
m/ring: 100
-
Copper index (kg/km): 0.1034 Lbs
-
Weight (kg/km): 0.1197 Lbs
-
Article number: 4724086
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
Lapp H07Z1-K Single Cable 4724086 1 x 16 Core and mm² Bare Copper Halogen Free Brown
Allowable Ampacity for Lapp H07Z1-K Single Cable 4724086 1 x 16 Core and mm² Bare Copper Halogen Free Brown: 100 Amp
Application range:
- For wiring of lamps, devices, switchgear cabinets and distribution boxes
- For installation in tubes, on, in and under plaster as well as in closed installation ducts
- In building with a high density of people or valuable assets
- For use in dry rooms
- For expanded ambient temperatures
see ÖLFLEX® HEAT 125 SC
Also Known As:
H05Z1-K Cable, Control Cable, Core Cable, Copper Cable, Halogen Free Cable, Dry Cable, ÖLFLEX® HEAT 125 SC
Benefits:
- Protection of human life and the environment thanks to the avoidance of the formation of acid in case of fire
- Time-saving assembly
Product features:
- The insulation material is halogen-free and free of other materials which could release toxic gases in the event of fire
- Low amount of corrosive gases in the event of fire
- Low smokes/low smoke density in the event of fire according to IEC 61034
- Flame-retardant according IEC 60332-1-2
Norm references / Approvals:
- <HAR> cable type certification acc. EN 50525-3-41
Product Make-up:
- Fine-wire strand made of bare copper wires
- Core insulation: Halogen-free
Technical Data:
-
Classification ETIM 5: ETIM 5.0 Class-ID: EC000993
ETIM 5.0 Class-Description: Single core cable
-
Classification ETIM 6: ETIM 6.0 Class-ID: EC000993
ETIM 6.0 Class-Description: Single core cable
-
Conductor stranding: Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5
-
Minimum bending radius: According to EN 50565-1 4 x outer diameter (OD) for normal use; 2 x OD for cautions bending
-
Nominal voltage: U0/U: 300/500 V
-
Test voltage: 2000 V AC
-
Current rating: VDE 0298-4 EN 50565-1/ VDE 0298-565-1
-
Temperature range: During installation: +5°C bis +90°CFixed installation: -40°C bis +90°C
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
