Indoor/Outdoor Distribution Series Laser Ultra Fox FRP 6 Fiber PVC Multimode 900µm Tight Buffer Orange Riser Cable DX006DWLS9ORF1
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Tensile Load | Menimum Bend Radius | |||||||
| Diameter | Weight | Installation | Operational | Installation | Long Term | |||
| Fiber Count | Fiber Type | Part Number | mm/(in) | kg/km (lbs/1,000) | N (lbs) | N (lbs) | cm (in) | cm (in) |
| 6 | WLS - 62.5µm OM1 | DX006DWLS9ORF1 | 9.7 (0.38) |
95.0 (67.20) |
1,400 (310) |
450 (100) |
14.6 (5.7) |
9.7 (3.8) |
APPLICATIONS:
• Used in areas that require a riser rating and are susceptible to damage from small non-burrowing rodents
STANDARDS:
OCC Indoor/Outdoor tight-buffered fiber optic cables meet the functional requirements of the following standards:
• UL 1666
• UL 1651
• GR-409-CORE
• ICEA-S-104-696
• ICEA-S-83-596
• TIA-568
• TIA-598
CHARACTERISTICS:
| Characteristic | Rodent Deterrent |
| Operating Temp | -40°C to +85°C |
| Storage Temp | -55°C to +85°C |
| Install Temp | -10°C to +60°C |
| Flame Retardancy | UL listed type OFNR (UL 1666) for all fiber counts *FT4 (CSA C22.2 No. 232) for 2-24 fiber counts only |
| Crush Resist | 1800 N/cm |
| Impact Resist | 1500 impacts |
| Flex Resist | 2000 cycles |
| Jacket Type | D |
FEATURES:
• Includes a layer of fiberglass yarn that provides an effective deterrent to damage caused by small non-burrowing rodents(not recommended for direct burial applications)
• FRP is ideal for use in surface installations
• 2 to 144 fibers
• Helically stranded cable core for flexibility, survival in difficult pulls, and excellent mechanical protection for the optical fibers
• Cables are suitable for use with single, as well as multichannel connectors
• Water resistant and UV resistant for extreme environments
Download PDF Spec Sheet
