Product Information

Specification

Igus 12-Pin Female Speedtec/9-Pin Male DSUB Connector B&R i8BCRxxx.1111A-0 Resolver Cable

Also Known as:

Resolver Connector, Igus DSUB Connector, IGUS, Intercontec Connector, IGUS Resolver Connector, B&R Connector

Construction:

• Conductor: Very finely stranded special cores of particularly high-flex design made of bare copper wires.

• Conductor Insulation: Mechanically high-quality TPE mixture

• Conductor Construction: 2 cores each stranded in pairs with short pitch lengths, core pairs also stranded with short pitch lengths.

• Conductor Identification: Colour code according to DIN 47100

• Overall shield: Extremely bending-resistant braiding made of tinned copper wires. Coverage approx. 70% linear, approx. 90% optical.

• Jacket Color: Silver grey (similar to RAL 7001)

• Outer jacket: Low-adhesion, oil-resistant mixture on the basis of PVC, adapted to suit the requirements in e-chains® (following DIN EN50363-4-1)

Properties and Approvals:

• Oil Resistance: Oil-resistant according to DIN EN 50363-4-1
• Flame retardant: According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1
• Silicone-free: Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992).
• UL/CSA AWM: See data sheet for details
• NFPA 79: Following NFPA 79-2012 chapter 12.9
• EAC: Certified to no. TC RU C-DE. ME77.B.01254
• CTP: Certified to no. C-DE.PB49.B.00416
• Lead free: Following 2011/65/EU (RoHS-II)
• CEI: Following CEI 20-35
• Clean room: According to ISO Class 1. Outer jacket material complies with CF240.02.24, tested by IPA according to standard 14644-1
• CE Guideline: Following 2014/35/EU

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
