Die-Cut Self-Laminating Label Cassette Printer Vinyl White S050X125VAM (Pack Of 5)
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
About :
The S050X125VAM Die-Cut Self-Laminating Label Cassette includes both label material and ribbon for easy changeover. Self-laminating adhesive labels for wire/cable identification include a white print-on area and a clear overlaminate. For use with the MP300 printer. Vinyl. 0.50" x 1.25" (12.7 mm x 31.8 mm). Wire/Cable Size Range 12 - 10 AWG. Color Clear/White.
Specification :
| Note | For use with MP300 printer |
| Product Type | Self-Laminating Label |
| Sub Brand | PXE |
| Color | White |
| Compatible Wire Gauge (AWG) | 12-10 |
| Material | Vinyl |
| Number of Labels per Cassette | 200 |
| Standards Met | RoHS Compliant |
| Minimum Cable Diameter (In.) | 0.12 |
| Minimum Cable Diameter (mm) | 3.1 |
| Maximum Cable Diameter (In.) | 0.28 |
| Maximum Cable Diameter (mm) | 7 |
| Label Height (In.) | 1.25 |
| Label Height (mm) | 31.8 |
| Label Width (In.) | 0.5 |
| Label Width (mm) | 12.7 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Maximum Operating Temperature (°C) | 66 |
| Maximum Operating Temperature (°F) | 150 |
| Print-On Area Height (In.) | 0.38 |
| Print-On Area Height (mm) | 9.7 |
| Label Application | Cable & Wire Marking |
| Overall Width (In.) | 0.5 |
| Overall Width (mm) | 12.7 |
Features :
• Crafted from high-quality vinyl material, these labels are designed to withstand harsh environments, ensuring longevity and readability even in challenging conditions. The die-cut design allows for precise, clean cuts, enhancing the professional appearance of your labels.
• The self-laminating feature adds an extra layer of protection, safeguarding your labels against moisture, chemicals, abrasion, and fading. This ensures that your labels remain clear and legible, maintaining their integrity over time.
