Corning 036TC8-14190-A3 36 Fiber OM4 50µm Plenum Multimode Ribbon Interlocking Armored Cable

Corning 036TC8-14190-A3 36 Fiber OM4 50µm Plenum Multimode Ribbon Interlocking Armored Cable
Roll over image to Zoom

Corning 036TC8-14190-A3 36 Fiber OM4 50µm Plenum Multimode Ribbon Interlocking Armored Cable

SKU: NNC25749X
corning-multi-fiber-50µm-plenum-multimode-ribbon-interlocking-armored-cable

Select a Gauge

Corning 036TC8-14190-A3 36 Fiber OM4 50µm Plenum Multimode Ribbon Interlocking Armored Cable
Min Length: 1 FT
Max Length: 10000 FT
Price:
Regular price
$0.00 /FT
Sale price
$0.00 /FT
Shipping Cost Calculated at Checkout. Standard Lead Time is 1 to 6 Business Days.
Free Shipping: On orders above $1000
Quantity must be 1 or more

Enter the required footage in the quantity box - Cut to one length

Where are we? 4 Continents 8 Countries

map
garrie

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Product Information

Specification

Description:

•
Corning ribbon interlocking armored plenum cables are designed for use in plenum, riser and general-purpose environments for intrabuilding backbone and horizontal installations. These cables are standard ribbon plenum cables placed inside spirally wrapped aluminum interlocking armor for ruggedness and superior crush resistance. This special construction facilitates routing inside buildings, through riser shafts and air-handling spaces, to telecommunication rooms and to workstations. Ideal for heavy traffic or more challenging mechanical exposure conditions, this cable design consists of fibers organized into 12-fiber ribbons inside a central tube surrounded by dielectric strength members to provide tensile strength. The flexible interlocking armor offers up to seven times the crush protection of nonarmored cables, while a specially formulated flame-retardant outer jacket allows the design to meet the requirements of the NFPA 262 flame test. The 12-fiber ribbons have readily identifiable ribbon ID numbers and fiber colors with easy access to individual fibers.

Features And Benefits:

• Ribbon ID numbers and fiber colors
  Easily identifiable
• Precise fiber and ribbon geometries
  Excellent mass splicing yields
• Flame-retardant jacket
  Rugged and durable
• Flexible interlocking armor
  Up to seven times the crush protection compared to non-armored cables
• Common installations
  Indoor plenum, riser and general building applications

Standards:

• Listings: National Electrical Code® (NEC®) OFNP
• Design Criteria: CSA FT-6
• Test Criteria: ANSI/ICEA S-83-596

Temperature Range:

• Storage: -40 °C to 70 °C (-40 °F to 158 °F )
• Installation: 0 °C to 60 °C (32 °F to 140 °F )
• Operation: 0 °C to 70 °C (32 °F to 158 °F )

Chemical Characteristics:

• RoHS: Free of hazardous substances according to RoHS 2011/65/EU

Specification:

All-Dielectric NO
Armored YES
Cable Type RIBBON
Fiber Count 36
Fiber Type OM4 50 MICRON MULTIMODE
Flame Rating PLENUM (OFCP)
Rodent Protected NO

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
