Copper Compression Lug Connector Burndy YGHA29N
Description :
• HYLUG™ Copper Compression Terminal for Grounding; Heavy Duty; 1-Hole.
Specifications :
| Connector Type | Terminal |
| Die Index | 18 |
| Material | Copper |
| Physical Attribute - Number of Crimps Required | 2 |
| Plated | N |
| Plating Type | Unplated |
| Trade Name | HYLUG™ |
| Type | Terminals |
| UPC | 781810127070 |
| Dimension - B Length fraction | 1-9/50 in |
| Dimension - B Length inch | 1.18 in |
| Dimension - D inch | 1.27 in |
| Dimension - Hole Size inch | 0.56 in |
| Dimension - Hole Size mm | 14 mm |
| Dimension - L Length Overall mm | 81 mm |
| Dimension - Length Overall inch | 3.18 in |
| Dimension - N inch | 0.63 in |
| Dimension - Outside Diameter inch | 0.75 in |
| Dimension - Pad Width inch | 1.28 in |
| Dimension - Z inch | 0.64 in |
| Physical Attribute - Tongue Angle | Straight |
| Conductor - Copper Str Size | 250 kcmil |
| Conductor - Copper Str Size Range | 250 kcmil |
| Conductor Type |
|
| Certification - CSA Approved | No |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Standards - Industry Standards Met |
|
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
| Minimum Pack Quantity | 1 |
