Copper Compression Groundlink Connectors Burndy YGIBS283382N
Description :
• Copper Compression Connector, Cable to Steel, 2 AWG - 4/0 AWG, Angled Flange, 0.25" - 0.338" Thickness, 2 holes, 1/2" Stud.
• Features: An Irreversible Compression Ground Connection Which Allows Attachment To A Structural Steel Standard (Angled) Or Wide Flange (Parallel) Beam, Installed With A Required 5-Piece Die Set, Catalog PIBEAMKIT Or UIBEAMKIT, Die Index 1105, GROUNDLINK Connectors Are Made Of High-Conductivity Wrought Copper And Come Pre-Filled With PENETROX E Compound And Strip Sealed, Order Terminal Mounting Hardware Separately, I Beam Thickness Range: 0.25 - 0.312 IN, Suggested Compression Terminal: YGHA2C-2N, YGHA25-2N, Mounting Hardware Order Separately: TMHG-42, Length: 3 IN, I Beam Style: Standard Beam (Flange Angled), Terminal Pad Thickness: 0.19 - 0.26 IN, Die Index: 1105 Element A
Specifications :
| Application | For Direct Burial Cables |
| Connector Type | Tap |
| EU RoHS Indicator | Yes |
| I Beam Style | Standard Beam (Flange Angled) |
| Material | Copper |
| Plated | N |
| Plating Type | Unplated |
| Sub Brand | HYGROUND, GROUNDLINK |
| Trade Name | GROUNDLINK™ |
| Type | Taps |
| UPC | 781810039397 |
| Dimension - B Length fraction | 6 in |
| Dimension - B Length inch | 6.00 in |
| Dimension - I Beam Thickness inch | 0.400" - 0.462" |
| Dimension - L Length Overall mm | 152 mm |
| Dimension - Length Overall inch | 6.00 in |
| Conductor - Copper Str Size | 250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil |
| Conductor - Copper Str Size Range | 250 kcmil-500 kcmil |
| Conductor Type |
CU C Str-Size |
| Certification - CSA Approved | Yes |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) |
|
| Standards - Industry Standards Met |
|
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
| Minimum Pack Quantity | 1 |
