Copper Compression Groundlink Connectors Burndy YGIBS346132N
Description :
• GROUNDLINK™ Connector for Structural Steel Angled or Parallel Beam; 2 Pad Holes; #2 AWG-500 kcmil; 1/2" Stud, I-Beam flange Thickness: .550" - .613".
Specifications :
| Connector Type | Tap |
| I Beam Style | Standard Beam (Flange Angled) |
| Material | Copper |
| Physical Attribute - Number of Tapped Holes | 2 |
| Plated | N |
| Plating Type | Unplated |
| Trade Name | GROUNDLINK™ |
| Type | Taps |
| UPC | 781810039335 |
| Dimension - B Length fraction | 6 in |
| Dimension - B Length inch | 6.00 in |
| Dimension - I Beam Thickness Range inch | 0.501;0.525;0.550;0.562 |
| Dimension - I Beam Thickness inch | .550" - .613" |
| Dimension - L Length Overall mm | 152 mm |
| Dimension - Length Overall inch | 6.00 in |
| Conductor - Copper Str Size | 250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil |
| Conductor - Copper Str Size Range | 250 kcmil-500 kcmil |
| Conductor Type |
CU C Str-Size |
| Certification - CSA Approved | Yes |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) | UL467 |
| Standards - Industry Standards Met | UL467 |
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
| Minimum Pack Quantity | 1 |
