95mm CPU Cooler Fan With Heatsink LP4 Connector Type For Socket LGA1156/1155 With PWM

Product Information

Specification

95mm CPU Cooler Fan With Heatsink LP4 Connector Type For Socket LGA1156/1155 With PWM

Applications:

• Computer systems where the cooling fan does not need to run at full speed all the time, for lower power consumption and noise
• Replace a noisy or failed CPU cooler for an LGA1156/1155 system

Install an energy-efficient CPU cooler for a build/upgrade for the following system CPUs:

LGA1156:  Core i3 530~560, Core i5 650~760, 655K, 750S, Core i7 860~880, 860S, 870S, 875K

LGA1155: Core i3 2100, 21020, 2100T, Core i5 2300~2500, 2390T, 2400S, 2500K, 25000S, 2500T, Core i7 2600, 2600K, 2600S

Description:

The FAN1156PWM CPU Cooler with PWM Cooling Fan for Socket LGA1156/1155 systems provides reliable and efficient cooling for compatible Intel Core i3/i5/i7 CPUs.

With Pulse Width Modulation (PWM) technology, the fan speed can be dynamically controlled by the motherboard, so the fan runs at a speed that suits the operating conditions - lowering power consumption and fan noise when the system is idle, and delivering maximum cooling under full load conditions.

Features:

• 4-pin Pulse Width Modulation (PWM) motherboard connector
• 95mm Ever Lubricate Bearing fan design
• Aluminum heatsink construction

Connector(s):

• Connector Type(s): LP4 (4 pin, PWM)

Hardware:

• Number of Conductors: 4
• Fan Dimensions (Number / Dimensions): 95mm x 95mm x 25mm
• Fan Bearing Type: Ever Lubricate Bearing
• Heatsink Type: Aluminum
• Heatsink Dimensions: 95mm x 95mm x 20mm

Performance:

• Air Flow Rate: 65.61 (max) CFM
• Noise Level: <33 dBA
• MTBF: 40,000 Hours
• Fan RPM: 1000 ~ 3000 RPM

Power:

• Input Voltage: 12V DC
• Input Current: 350 mA

Environmental:

• Operating Temperature: -10C ~ 70C (14F ~ 158F)
• Storage Temperature:  -20C ~ 70C (-4F ~ 158F)
• Humidity: 0 ~ 65% RH

Special Notes / Requirements:

• System and Cable Requirements: Socket LGA1156/LGA1155 motherboard
