8 Port Unmanaged Ethernet Switch FUMS-FTX8

Product Information

Specification

8 Port Unmanaged Ethernet Switch FUMS-FTX8

Also Known As:

8 Port Ethernet Switch, Unmanaged Ethernet Switch, 8 Copper Ethernet Switch, 100 Mbps Ethernet Switch

About:

Unmanaged Switch, 8 Port, 100 Mbps, 8 Copper. The FUMS-FTX8 is an 8-port unmanaged Ethernet switch designed for transmitting and receiving 10/100 Mbps data over optical fiber using user-selectable Small Form-Factor Pluggable (SFP) modules, or 10/100 Mbps data over Cat5e or Cat6 electrical cables. The electrical interface automatically negotiates between 10 Mbps and 100 Mbps Ethernet speeds without requiring manual configuration, while the optical interface operates at a fixed 100 Mbps rate. This unit integrates either four or eight independent 10/100 Mbps channels in a single package. Its modular design allows for flexible installation, supporting both wall and rack mounting. LED indicators provide clear visibility of the operational status and critical performance parameters for easy monitoring.

Features:

• Hot-Swappable Rack Modules
• Compliant with IEEE 802.3 Standards
• Stand-Alone or Rack-Mountable Modular Design
• Optical Port Supports 100 Mbps Full-Duplex Data
• LED Status Indicators for Monitoring All Critical and Normal Operating Parameters
• Electrical Port Supports Autonegotiation for 10 Mbps or 100 Mbps,Full-Duplex or Half-Duplex Data
• Automatic Medium Dependent Interface/Medium Dependent Interface Crossover (MDI/MDI-X) Operation
• Designed to Meet NEMA TS 1/TS 2 and Caltrans Traffic Signal Control Equipment Environmental Standards
• Uses Interchangeable Small Form-Factor Pluggable (FSFP) Modules for Specific Fiber Type, Distance, and Connector (Must Be Ordered Separately)
• Voltage Transient Protection on All Power and Signal Input/Output Lines Provides Protection from Power Surges and Other Voltage Transient Events

Specifications:

• Product Type: Unmanaged Ethernet Switch
• No Exp Modules/slots: 1-2
• Number Of Ports: 5-12
• Part Number : FUMS-FTX8
