Specification

20 AWG 2 Conductor 7Strands Unshielded CMR FPLR Non-Plenum Sound And Security Cable

Applications:

Suitable for general-purpose use. Resistant to the spread of fire. Used in sound/audio systems, intercom/P.A. systems, security systems, power limited controls, and remote control signaling.

Also Known As:

20 AWG 2C Security Cable, 20 AWG 2C Sound Cable, 20 AWG 2C Non-Plenum, 20 AWG 2C FPLR,  20 AWG 2C Unshielded, 20 AWG 2C CMR Cable, 20 AWG 2C FPLR Cable, CW09217 Cable.

Construction:

Conductors:

SOLID OR STRANDED BARE COPPER.

Insulation:

POLYVINYL CHLORIDE (PVC); INSULATED CONDUCTORS TWISTED TOGETHER

Jacket:

GRAY POLYVINYL CHLORIDE (PVC).

Standards:

NEC Article 725 (Type CL3R, CL2R).
NEC Article 760 (Type FPLR).
NEC Article 800 (Type CMR).

Specification:

• Size: 20 AWG
• Number of Conductors: 2
• Conductor Stranding: 7
• Insulation Thickness: 0.009 inches
• Jacket Thickness: 0.015 inches
• Overall Diameter: 0.14 inches
• Approx. Weight: 0.01
• Color: Gray
• Part No: CW09217

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.

In the case the material only comes in a predetermined color or doesn’t come with any color
