18/6C Stranded Plenum Shielded PVC Security Alarm Cable 300V

18/6C Stranded Plenum Shielded PVC Security Alarm Cable 300V

Description:

Low smoke PVC insulated stranded bare copper conductors, twisted, aluminum mylar shielding with drain wire and an overall low smoke white PVC jacket* with rip cord.

Also Know As:

18/6C Security Alarm Cable, 18/6C Plenum Shielded Alarm Cable, 18/6C Riser Shielded Security Alarm Cable, 18/6C PVC Security Alarm Cable, 18/6C Plenum Security Cable.

Application:

• Security Systems
• Intercom Systems
• Sound/Audio System
• Power-Limited Controls

Conductor: Bare Copper

Insulation: Low Smoke PVC

Insulation:

• 22 AWG .007” PVC
• 20 AWG .008” PVC
• 18 AWG .009” PVC
• 16 AWG .010” PVC
• 14-12 AWG .012” PVC

Shield: Aluminum Mylar

Jacket: Low Smoke PVC

NEC Articles:

• 22-16 AWG: FPLP/760, CMP/800, CL3P/725
• 14-12 AWG: FPLP, CL3P

Voltage Rating: 300 V

Temp. Rating: -25C to 75C

Specification:

• Size: 18 AWG
• Conduuctors: 6C
• Strands: Solid
• Part Number: 911806SD
• CAP PF/FT: 65
• Outer Jacket Thickness: 0.015 Inches
• Nominal OD: 0.229 Inches
• Weight: 51 lbs/1000ft
