16CH 1080p DVR Penta-brid HDCVI DVR 1U dahua Tech X52B3A
Where are we? 4 Continents 9 Countries

Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Operating System | Embedded LINUX |
| Main Processor | Embedded Processor |
| Performance |
• Human and Vehicle object classification • Decreased false alarms from leaves, lights, animals • Configure function on 6 channels • 10 Tripwire/Intrusion rules per channel |
| Object Classification |
• Human or Vehicle • Secondary Recognition for Tripwire and Intrusion |
| Performance |
• Detect motion based on object classification (human or vehicle) • Decreased false alarms from leaves, lights, animals • Configure functions on 32 channels |
| Two-way Talk |
Input: One (1) Microphone, BNC Output: One (1) Channel, BNC |
| IP Camera Input |
32 Channels, each channel up to 12 MP (The recording rate is dependent on the maximum resolution and frame rate of the connected IP camera.) |
| Bit Rate |
32 Kbps to 6144 Kbps per Channel |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video Detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Part No | X52B3A |
16CH 1080p DVR Penta-brid HDCVI DVR 1U dahua Tech X52B3A
DESCRIPTION :
The X52B Series HDCVI DVR offers high-definition recording on each HDCVI channel and a host of advanced features and functions. The X52B takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously. This recorder is the ideal solution for actively monitoring retail stores, personal property and homes.
FEATURES :
⦿ 5M-N/1080p Recording Resolution on All HDCVI Channels
⦿ Available with a 4 TB, 6 TB, 8 TB, or 10 TB Pre-installed Hard Drive
⦿ Dual-stream Video Recording
⦿ AI Coding Technology for High-quality Human/Vehicle Video
⦿ Auto-detection and Auto-configuration of Video Inputs
⦿ 16 + 8 IP Camera Channels, each channel up to 6 MP
⦿ Maximum 128 Mbps Incoming Bandwidth
⦿ Perimeter Protection and Smart Motion Detection (SMD)
⦿ Long-distance Video Transmission
⦿ Five-year Warranty (for products sold through an authorized Dahua Dealer)
Download PDF Spec Sheet
