14 AWG 2C W/G Type THW HI-LO Supreme Parallel Water Well 600 Volt Cable

14 AWG 2C W/G Type THW HI-LO Supreme Parallel Water Well 600 Volt Cable

Applications & Features:

For use in residential, farm and industrial water well applications. Used in both Grounded and ungrounded water well cable systems. Conductors are parallel and insulated with PVC colored black, red, and yellow. Insulated and jacketed with a premium thermoplastic elastomer (TPE) material. Oil resistant. Used in both high temperature and low temperature wells.

600V Extreme, Oil-Resistant, Moisture Resistant Conditions. Rated -50°C to +105°C.

Also Known AS:

14 AWG 2C THW Water Well Cable, 14 AWG 2C Submersible Pump Cable, 600V Water Well Cable, 14 AWG 2C HI-LO Supreme Well Cable, Parallel Water Well Cable, 600V Submersible Cable, 14 AWG 2C Thermoplastic Well Cable, Heavy Duty Water Well Cable

Constructions:

Conductor:
Class K, flexible stranded soft drawn bare copper per ASTM B172

Insulation:
Polyvinyl Chloride (PVC) Type THW

Jacket:
Thermoplastic elastomer (TPE)

Standards:

• ASTM B172 Standard Specification for Rope-Lay-Stranded Copper Conductors Having Bunch-Stranded Copper Conductors
• UL 83 Thermoplastic Insulated Wires and Cables

Specifications:

• Size:14 AWG
• Number of Conductors: 2
• No of Strands: 41
• Diameter Over Conductor (inch):  0.073
• Insulation Thickness (Mil): 30
• Ground No. x AWG:  1 x 14
• Jacket Thickness (Mil):   25
• Approx. OD (In):  0.188 X 0.464
• Approx. Weight (Lbs/1000'Ft): 65
• Allowable Ampacity At 75°C (Amp):   20
• Allowable Ampacity 90°C (Amp): 25
