1 Channel Single-Mode Bi-Directional Receiver FC Connector FRV10D1A2S1FC

Product Information

Specification

1 Channel Single-Mode Bi-Directional Receiver FC Connector FRV10D1A2S1FC

Also Known As:

1 Channel Receiver, Single-Mode Receiver, FC Connector, Bi-Directional Receiver

About:

The FRV10D1A2S1FC Fiber Receiver enables the simultaneous transmission of one bidirectional video channel, one bidirectional data channel, two bidirectional audio channels, and one bidirectional contact closure over a single optical fiber. This unit comes in a two-slot wide design and is available in single-mode versions. For high-quality audio transmission, it provides two bidirectional 24-bit (96 kHz) audio signals with digital encoding, ensuring superior balanced line-level audio. The data channel supports various communication protocols, including RS-232, RS-422, RS-485 (2-wire/4-wire), Manchester, and Bi-Phase. The FRV10D1A2S1FC is designed for easy installation, with a plug-and-play configuration that requires no electrical or optical adjustments. Its modular structure allows for rack mounting using the EURACK/USRACK chassis or standalone installation. The unit can also be wall-mounted without needing a wall mount kit. For standalone or wall-mounted setups, external power is required and can be supplied via the recommended FEXTPS fiber external power supply.

Features:

• Laser Diode for Transmission of Optical Signals
• Compatible NTSC, PAL, and SECAM Video Standards
• Single-Mode Support for Distances up to 48 km (29.8 mi)
• Exceeds All Requirements for the EIA RS-250C Short-Haul Transmission Specification
• Designed to Meet NEMA TS 1/TS 2 and Caltrans Traffic Signal Control Equipment Environmental Standards

Specifications:

• Product Type: Receiver
• Part Number : FRV10D1A2S1FC
