1.5MHz Current Probe CP6990-NA
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Type | Active Current |
| Measurement Ranges | 1 V/A / 100 mV/A |
| Current (DC + peak AC) | 4 A / 40 A |
| Bandwidth | DC - 1.5 MHz |
| Rise and Fall Time | 0.23 µs (typ.) |
| Battery Life | 4 hours |
| Max. Cable Diameter | 10.3 mm (0.4") |
| Dimensions |
262mm x 81mm x 36mm (10.3" x 3.2" x 1.4") |
| Weight | 310 g w/o battery |
| RoHS 2 | Compliant |
| Part No. | CP6990-NA |
1.5MHz Current Probe
Description:
The active clamp-style current probe offers dual sensitivity ranges of 1 V/A and 100 mV/A, allowing current measurements up to 4 A and 40 A, respectively. It provides a bandwidth of up to 1.5 MHz in both ranges and is powered either by a 9 V battery or the included AC power adapter (CT3957-#).
Features:
• Compact stylish body
•1.5 MHz bandwidth (-3 dB)
• Over-range indicator
• Dual sensitivity ranges
Kit contains:
• Current probe
• Insulated BNC Cable
• BNC to Banana Plugs Adapter
• AC Power Adapter
• User Manual
Download PDF Spec Sheet
