0.09 22-18 AWG Reel Smart Female Disconnect Vinyl Barrel Insulated DV18-188B-3K (Pack of 3000)

Product Information

Specification

About:

This vibration-resistant female disconnect is made from brass with a tin-plated finish, offering excellent durability and resistance to corrosion. It features barrel insulation housed in a red vinyl casing for enhanced protection and insulation.

Designed for tab sizes of 0.187 x 0.02 inches (4.8 x 0.5 mm), it accommodates wire ranges from 22 to 18 AWG (0.5 to 1.0 mm²). The disconnect measures 0.77 inches (19.6 mm) in length and 0.23 inches (5.8 mm) in width. It is equipped with a funnel entry barrel configuration and a butted seam barrel, which ensure easy wire insertion and a reliable connection. This disconnect is supplied in reels of 3000, making it ideal for high-volume wiring projects.

Also Known As:

• Crimp-on Female Connector
• Female Spade Terminal
• Insulated Quick Disconnects
• Slip-on Terminal

Common Applications:

• Industrial machinery wiring
• Consumer electronics
• Automotive electrical systems
• Any application where quick and reliable wire terminations are needed for service or maintenance
• HVAC control wiring
• Power supplies and distribution panels

Standards:

• UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153

Construction:

• A vinyl insulation sleeve that covers the crimped area of the terminal, providing basic insulation.
• A conducting metal (often copper or brass) for the terminal itself, which is crimped onto a wire.
• The vinyl insulation can also come in different colors for wire size identification and to indicate different electrical functions or phases.

Features:

• Internal barrel serrations assure good wire contact and maximum tensile strength

• Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost

• Continuously molded design provides reliable, consistent performance through the applicator for a high quality termination every time

• UL and CSA rated up to 600 V per UL 310, where applicable

• Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection

• UL Flammability UL 94V-0, maximum insulation temperature 221°F (105°C)
