2" Type 375 Socket/FPT Ends True FPM O-rings CPVC Union Ball Valve 163.375.022

Product Information

Specification

Ball Type	Standard
Connection Type	S/FPT
Operator	Handle
O-Ring Material	FPM
Seat Material	PTFE
Series	Type 375
Size	2"
Type of product	True Union Ball Valve
Ball Material	CPVC
Body Material	CPVC
Part Number	163.375.022



2" Type 375 Socket/FPT Ends True FPM O-rings CPVC Union Ball Valve 163.375.022

Description

Complement valve to the ball valve Type 546 for non-critical applications. The ball valve Type 375 offers you a basic PVC true union ball valve. Actuation is not available for the 375.

Features

• True union design with PTFE seats
• Sizes ½-2" include threaded and socket end connectors
• NSF-certified
• Blow out proof stem
• Rated to 232 psi for socket and 150 psi for threaded version
• Adjustable seat carrier
