Precision Tube and Wire Cutting Machines Stainless Steel SLICE 230

Product Information

Specification

Precision Tube and Wire Cutting Machines Stainless Steel SLICE 230

Description

This heavy-duty automated measuring and cutting machine, designed by AMTI, features HMI control and PLC programmability for precise and efficient operation. Engineered to handle a wide range of materials including heat shrink tubing, convoluted loom tubing (slit and un-slit), hose, tubing, braided bus, multi-conductor cable, and heavy gauge wire up to 2 AWG it offers both single and multi-cut capabilities. With multiple programmable inputs and outputs, it supports application specific integrations to reduce labor and enhance accuracy. Comparable to the SLICE 141, this model excels at cutting larger cables and includes quick-change blades for fast setup and easy maintenance.

Features

• User friendly HMI interface.
• PLC programmable inputs and outputs.
• Quick change 3 inch wide blade design.
• Aluminum, stainless steel and hardened tool steel construction.
• Adjustable feed rate from 5”-30” per second.
• Adjustable throat opening height (Range 0” to 1.5”).
• Adjustable drive tension with three poly or stainless steel drive wheels and one tracing wheel to enhance pulling action from large spools/reels.
• Adjustable exit chute guides. Shrink tube stick mode for continuous feed Up to 99 stored standard programmable setting and customizable batch programs.
• Measures and cuts in your choice of inches or millimeters Accuracy is within plus or minus 1.0 millimeter material dependent.
• All air filters and regulators are included.
