Mounting Ladder Bracket for Fiber Pathways Black Panduit FLRB

Product Information

Specification

Product Type	Ladder Rack
Color	Black
Overall Height	4.57
Overall Length	6.56
Overall Width	1.25
For Use With	Mounting Channel to Bracket
Series Type	2x2 and 4x4 Fiber-Duct Brackets

Mounting Ladder Bracket for Fiber Pathways Black Panduit FLRB

Description:

The steel ladder bracket is used in cable routing systems to support the 2x2 and 4x4 FiberRunner Systems by directly attaching to any 0.375 inches H x 1.5 inch L (9.5mm x 38.1mm), or 0.375 inches H x 2 inch L (9.5mm x 50.8mm) ladder rack rails. It does not require a threaded rod. The ladder bracket includes hardware for mounting the channel to the bracket.

specifications:

• The 2x2 and 4x4 routing systems shall be used to route, segregate, and protect fiber optic and communication cabling. The solid wall routing systems should be UL Listed as an optical fiber channel for general-purpose use.
• They shall be compliant with UL 2024A and NEC articles 770 and 800 when installed per instructions.
• The slotted wall channel and cover shall be UL Recognized.
• A full complement of fittings with a 2" minimum bend radius, snap-on covers, and mounting brackets shall be available.
• Channel and fittings shall be manufactured from impact-resistant and flame-retardant (V-0) materials. Channel shall have non-slip snap-on covers that can be easily removed to allow access for moves, adds, and changes.
• Channel and fittings finish shall be pure color, resist scratches, and dents, and not peel or corrode.
• Available system colors shall be yellow, orange, black, and light gray.
• A full complement of brackets shall be available for attaching system components to ladder racks, threaded rods, auxiliary framing, equipment racks, and raised floor pedestals.
