Metal Micro USB 2.0 Female to Female Connector with Cap PCM-0608 (Pack of 10)
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
About :
Metal Micro USB 2.0 Female to Female Waterproof Panel Mount Connector with Cap
Waterproof Micro USB Coupler IP68 Rated with Dust Cap, IP67 Waterproof Panel-Mount USB Micro-B 2.0 Female-Female Adapter, Waterproof USB Micro-B to Micro-B Adapter
Also Known As :
USB Connector, USB Cable, Adapter, USB Adapter, USB Cable, Electronics Components, Components, Connectors, Female Adapter, Female Connectors
Specification :
| Connector | Micro USB |
| Panel Mount Type | Screw Locking Mechanism |
| Shell Material | Copper Shell |
| Salt Spray Test | 72H |
| Panel cut-out size | Diameter : 25mm |
| Certificate | UL, Rohs, Reach |
| Gender | Micro USB Female to Female |
| IP Grade | IP67 When Mated |
| Description | This waterproof and dustproof USB Micro-B Adapter features a panel-mount IP67 rated. |
| Part No. | PCM-0608 |
• O-rings provide IP67-rated water and dust protection.
• Circular threaded coupling mounts case side to connect with Adapter side connector.
• To achieve waterproof/IP67 protection, the outside Micro USB connection must be sealed with waterproof Adapter gland.
Application :
• Marine
• Process Control
• Portable computers
• Harsh environments
• Factory automation
• Medical equipment
• Industrial computing
• Outdoor environments
• Industrial Touch Monitor
• Portable broadcast equipment
• Outdoor Embedded Touch Monitor
• Outdoor audio / video equipment
• Full IP67 High Brightness Touch Monitor
Download PDF Spec Sheet
