Indoor/Outdoor Distribution Series Ultra Fox 12 Fiber Low Smoke PVC Single Mode 900µm Tight Buffer Yellow Plenum Cable DZ012TSLX9YP
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
| Tensile Load | Menimum Bend Radius | |||||||
| Diameter | Weight | Installation | Operational | Installation | Long Term | |||
| Fiber Count | Fiber Type | Part Number | mm/(in) | kg/km (lbs/1,000) | N (lbs) | N (lbs) | cm (in) | cm (in) |
| 12 | SLX - SM ITU-T G.652.D | DZ012TSLX9YP | 6.2 (0.24) |
34.0 (24.15) |
660 (150) |
200 (45) | 12.4 (4.9) |
6.2 (2.4) |
DESCRIPTION:
Offering the durability you expect from OCC, these distribution cables provide all of the indispensable elements needed for Indoor and Indoor/Outdoor commercial applications, while providing great value. Manufactured with Indoor/Outdoor grade low smoke PVC for plenum applications.
CHARACTERISTICS:
| Characteristic | DZ-Series - Plenum Rated Cables |
| Operating Temp | -40°C to +70°C |
| Storage Temp | -40°C to +70°C |
| Install Temp | -10°C to +60°C |
| Flame Retardancy | UL Listed Type OFN NFPA262 FT6 (CSA C22.2 No. 232) |
| Jacket Type | Indoor / Outdoor Low Smoke PVC |
FEATURES:
• Ease of Termination
• Product in Inventory / Short Lead Time
• Lightweight
• Designed & Manufactured in the USA
• Industry-Leading Fiber Performance Specification
• Manufactured with OCC’s Industry-Leading Polymers
• Covered by OCC's 25yr Channel/Link Limited Warranty
• A Versatile Choice for Indoor/Outdoor Use
• Available in Indoor/Outdoor Riser (OFNR), or Plenum (OFNP)
• Available in 4-24 Fibers
• Colors Available: Aqua, Black, Orange, and Yellow
• ICEA 696 Compliant
• Water Blocked
• -40°C to + 70°C Temperature Range
• RoHS & Reach Compliant
• Bend Insensitive Fibers are Standard
Download PDF Spec Sheet
