Eaton Crouse-hinds Series ARK-GARD ENP Plug - ENP5151

Product Information

Specification

 EATON CROUSE-HINDS SERIES ARK-GARD ENP PLUG - ENP5151

Decription :-

Eaton Crouse-Hinds series Ark-Gard ENP plug, 15A, 50-400 Hz, Copper-free aluminum, 5-15P, 125 Vac

Key Features :-

1. ⦿ Captive set screw design is now standard on all ENP plugs
2. ⦿ Design assures ease of installation and reduces likelihood of losing critical components in the field
3. ⦿ Insulator and contact components are now a single piece assembly
4. ⦿ ENP plugs can be used in non-hazardous areas with standard U-ground NEMA/ EEMAC configuration 5 and 6 receptacles, eliminating the need for two separately equipped portable units of the same type; the ENR receptacle will not accept standard NEMA/EEMAC configuration plugs
5. ⦿ ENP plug handle body is designed with an internal cord strain relief mechanism and a cable sealing grommet which will accept various cable diameters
6. ⦿ Field assembly is accomplished with standard tools
7. ⦿ Ark-Gard 2 receptacle incorporates three spring-loaded slide keys that prevent the receptacle face plate from being rotated until the ENP plug is fully inserted into the receptacle. To make the connection, the ENP plug is fully inserted, and the receptacle face moved inward by pushing the plug forward. The plug is then rotated, closing the circuit. As rotation begins, the plug becomes locked in the receptacle and cannot be accidentally disengaged. In making or breaking the circuit, any resulting electrical arc is confined in the factory sealed chamber.
