Dri-Lite Gel Free Armored Direct Burial Fiber Optic Cable 24 Strand Loose Tube Singlemode SUPERIOR C 12024KD0L

Product Information

Specification

Dri-Lite Gel Free Armored Direct Burial Fiber Optic Cable 24 Strand Loose Tube Singlemode SUPERIOR C 12024KD0L

Also Known As:

Dri-Lite 24-strand armored cable, Dri-Lite direct burial fiber, Dri-Lite OSP fiber, 24-strand armored fiber, Gel-free buried fiber, Superior Essex 24-strand fiber, direct burial fiber optic cable, single mode fiber optic cable, aerial fiber optic cable, 24 strands fiber optic cable

Description:

Superior Essex Loose tube 24-strand fiber optic cable is designed for Outside Plant (OSP) environments. It is a fiber optic direct burial cable. The rugged loose tube design offers reliable transmission performance over a broad temperature range. The core is constructed by stranding the buffer tubes around a central member using a reverse oscillating lay (ROL). The core is wrapped with flexible strength members covered with water-blocking tape. A corrugated steel armor is applied and then encased with a black jacket. Ripcords are included under the armor for ease of entry.

Common Applications:

The cable is suitable for outside plant direct burial, conduit, and aerial applications.

Common applications include

• OSP Networks
• Broadband and Telecom Installations
• Long-Haul Data Transmission
• Remote Sensing
• Connectivity in Data Centers
• High-capacity transmission in corporate settings
• Large scale telecommunication setups
• Fiber-to-the-home (FTTH) projects
• Surveillance Systems in sensitive areas

Features:

• 2 Gel free buffer tubes with 12 fibers each
• Core is helically wrapped with fiberglass strength members
• Super absorbent polymer tape for water blocking
• Sunlight UV resistant MDPE jacket sequentially marked

Construction:

Core:

The core employs a unique reverse oscillating lay (ROL) technique, ensuring the buffer tubes are perfectly stranded around a central member.

Protection:

Enhanced protection with the use of super absorbent polymer tape, offering impeccable water resistance. This ensures longer lifespan and consistent performance.

Armor:

A resilient corrugated steel armor safeguards the cable, providing it with the necessary toughness for OSP applications.
