8 Port Unmanaged Ethernet Switch FUMS-GFX8

Product Information

Specification

8 Port Unmanaged Ethernet Switch FUMS-GFX8

Also Known As:

8 Port Ethernet Switch, Unmanaged Ethernet Switch, 1000 Mbps Ethernet Switch

About:

The FUMS-GFX8 from Pelco is an 8-port unmanaged Ethernet switch designed to transmit and receive 10/100/1000BASE-T(X) or 1000FX data through user-selectable Small Form-Factor Pluggable (SFP) transceivers (sold separately). Its plug-and-play design ensures easy installation without requiring electrical or optical adjustments. The modular design allows for either wall or rack mounting, providing flexibility in deployment. LED indicators display real-time operating status and key parameters for monitoring. This switch is built to operate in extreme environments, making it ideal for demanding applications. The FUMS-GFX8 requires external power, which can be supplied through the recommended FEXTPS fiber external power supply. With its optical transmission capabilities, this switch is perfect for supporting Ethernet-compatible IP camera surveillance in transportation systems, airports, and college campuses.

Features:

• Hot-Swappable Rack Modules
• Compliant with IEEE 802.3 Standards
• Stand-Alone or Rack-Mountable Modular Design
• Optical Port Supports 1000 Mbps Full-Duplex Data
• LED Status Indicators for Monitoring All Critical and Normal Operating Parameters
• Electrical Port Supports Autonegotiation for 10/100/1000 Mbps, Full-Duplex or Half-Duplex Data
• Automatic Medium Dependent Interface/Medium Dependent Interface Crossover (MDI/MDI-X) Operation
• Designed to Meet NEMA TS 1/TS 2 and Caltrans Traffic Signal Control Equipment Environmental Standards
• Uses Interchangeable Small Form-Factor Pluggable (FSFP) Modules for Specific Fiber Type, Distance, and Connector (Must Be Ordered Separately)
• Voltage Transient Protection on All Power and Signal Input/Output Lines Provides Protection from Power Surges and Other Voltage Transient Events

Specifications:

• Product Type: Unmanaged Ethernet Switch
• Part Number : FUMS-GFX8
