50' DisplayPort Active Optical Cable 8K 60Hz/4K 120Hz Video HDCP 2.2 HDR10 HBR3 Fiber Optic DisplayPort 1.4 Cable

Product Information

Specification

50' DisplayPort Active Optical Cable 8K 60Hz/4K 120Hz Video HDCP 2.2 HDR10 HBR3 Fiber Optic DisplayPort 1.4 Cable

Applications:

• Deliver enriched presentations using 8K projectors.
• Connect 8K displays as part of a digital signage wall

Description:

This active optical DisplayPort 1.4 cable lets you connect your DP laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. The built-in active signal booster ensures a reliable connection at a distance up to 15 m (49.2 ft.) between your DisplayPort enabled devices. This durable yet lightweight active DP 1.4 cable features both copper and optical fiber conductors enabling a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed. The DisplayPort connectors also feature latches that provide a secure connection between your devices. Comprised of a fiber and copper wire mix, this active cable is less susceptible to EMI interference, for a clear and reliable audio/video signal.

Experience What DisplayPort 1.4 Has to Offer:

This 8K DisplayPort cable supports all DP 1.4 features:

• Resolutions up to 8K at 60Hz
• HDCP 2.2 support
• High Bit Rate 3 (HBR3) bandwidth of 32.4Gbps
• High Dynamic Range (HDR)
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• 32 uncompressed digital audio channels
• Backward compatible with 5K 60Hz, 4K 120Hz and previous generations of DP

Hardware:

• Number of Conductors: 19
• Connector Plating: Nickel
• Cable Jacket Material: PVC - Polyvinyl Chloride
• Cable Shield Material: Aluminum-Mylar Foil with Braid

Connector(s):

• Connector A: 1 - DisplayPort (20 pin)
• Connector B: 1 - DisplayPort (20 pin)
