5 Meters Fiber Optic Jumper and LC Duplex to LC Duplex Connector With Standard Yellow Jacket 040402R5816005M
Where are we? 4 Continents 9 Countries
Got any Questions?
Speak with a real person who will go out of their way to help you!
Call Us: 1-516-482-6313Text Us: 1-516-703-3460
Quick Support
Product Information
Specification
General Specifications
| Cable Type | Tight-Buffered |
| Cable Assembly Type | Two Fiber |
| Fiber Category | 50 µm MM (OM4) |
| Application | General Building Applications, Indoor Horizontal, Plenum |
| Flame Rating | Plenum (OFNP) |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
Design
| Fiber Count | 2 |
| Outer Jacket Color | Yellow |
Connector A
| Connector Type | LC Duplex |
| Ferrule Material | Ceramic |
| Housing Material | Composite |
| Boot Color | Blue |
| Housing Color | Blue |
Connector B
| Connector Type | LC Duplex |
| Ferrule Material | Ceramic |
| Boot Color | Blue |
| Housing Color | Blue |
5 Meters Fiber Optic Jumper and LC Duplex to LC Duplex Connector With Standard Yellow Jacket
Description
Two-fiber cable assemblies are offered with a variety of connector and cable combinations. Connector options include LC, SC, FC, ST compatible, and MT-RJ. RoHS-compliant Zipcord, DFX, MIC, Fan-out, and RIC cables are available. Additional detailed fabrication images are available in the Cable Assembly Family Specification Sheet.
Features
⦿ Flame-retardant jacket: Rugged and durable
⦿ Superior Performance Testing: Every termination is tested to ensure the highest in network performance
⦿ State-Of-The-Art Manufacturing Processes: Corning proprietary manufacturing processes and advanced technology result in unsurpassed product consistency
⦿ Corning advantage: integrated developer and manufacturer of cable, connectors, and fiber to ensure overall cable assembly performance.
Download PDF Spec Sheet
