5/32" Push-to-Connect D.O.T. Push-In Plug Brass Fittings 595320

Product Information

Specification

5/32" D.O.T. Push-In Plug Brass Fittings 595320

Description:

5/32 D.O.T. PUSH-IN PLUG

Benefits for Cost Savings & Engineering Project:

Fast assembly:

• No tools are required. Simply push the tubing in.

• Saves up to 75% of assembly time compared to standard air compression fittings.

• No loose parts to handle.

 Fast disconnect:

• Hold the collet collar with two fingers and pull out the tube.

• No tools are required.

• Reusable:

• Can be connected and disconnected several times.

Reliable sealing:

•  Using recommended tubing, full sealing is guaranteed.

Versatility:

• Buna N O'ring standard. Fluoroelastomer and others are available per request.

• Secure tube retention. Pulling on the tubing only serves to tighten the connection.

• Pre-Applied Polytetrafluoroethylene® based pipe sealant on all male pipe threads, saving customers additional labor.

• Full Flow Design provides more flow area than conventional fittings with internal tube supports even in the swivels.

• Materials: Brass "O" Ring: Buna-Nitrile (90 Durometer) EP (Ethylene Propylene)

Working Pressures & Temperature Ranges:

• Vacuum to 150 PSI -40°F to 200° F ( -40°C to +93°C )

 • D.O.T. PUSH-IN TUBE FITTINGS Meets D.O.T. FMVSS 571.106 SAE J1131 Air Brake System RequireDOT Fittings are constructed with an all brass captive eyelet which allows for maximum flow.

•  The brass captive eyelet with extended length is floating and has a machined top-end radius for easy installation of tubing.

•  All male threads have a pre-applied Polytetrafluoroethylene® based pipe sealant to provide for easy assembly and leak-proof seal.
