3/4" Lead-Free Csa Full Port Ball Valve Threaded and Sweat 943234LF

Product Information

Specification

3/4" Lead-Free Csa Full Port Ball Valve Threaded and Sweat 943234LF

Description:

3/4 LEAD-FREE CSA FULL PORT BALL VALVE

Features:

• Maximum operating temperature: 248°F (120° C) at 600 PSI
• Minimum operating temperature: -20°F (-40°C)
• Each valve individually tested
• Forged Brass - for more strength
• Threaded ends to ANSI B1.20.1
• Hard chromium-plated solid ball
• Bottom entry, blow-out proof stem
• Deeper threads - for better connections

Solid Chrome Plated Brass Ball:
• Suitable for a full range of liquids and gases
• Minimal pressure drop due to large full-size ports
• Bottom-loaded, pressure-retaining stem
• Pressure rated at 600psi (42 bars) WOG (non-shock) and 150 WSP (10.34 bars) saturated steam. Virgin TFE stem packing seal, thrust washer, and seats.
• Blue vinyl insulator on heavy-duty plated carbon steel handles.
• Fast 1/4 turn open or close operation
• Low operating torque
• Flow can go both directions
• Adjustable stem-packing gland
