18 AWG Gauge 16 Conductor Blue Jacket Marine Wire
Also Known As:
Marine Battery Cable, Durability Cable, Flexibility Cable, Gauge Marine Wire, Highest Quality Cable, Blue Jacket Cable
About:
Marine wire is designed to handle the harshest marine environments. It is manufactured to meet and exceed the most stringent specifications. This 18 AWG marine wire is constructed in-house to achieve the highest level of quality. Built from Type III class K tinned copper, this wire offers excellent flexibility. The tinned copper also resists corrosion adding to the life of the wire. What about the insulation? After the copper is tinned it is then insulated with a durable and flexible PVC jacket. The jacket makes this 18 AWG marine wire resistant to alkali, abrasion, acid, gas, oil, flame and moisture. What standards and compliances does this wire meet? Pacer Group's marine wire exceeds the requirements and standards of UL, ABYC and NMMA.
Applications:
• Point to point wiring
• Internal wiring of panels and motors
Construction:
• AWM 1015/1230
• CSA: TEW
• Temperature Rating: 105 °C Dry, 60 °C Wet
Standards:
• Conductor: Type III annealed finely stranded tinned copper ASTM B172 Class K
• Insulation: -20 °C to 105 °C flexible, color coded PVC
• Voltage Rating: 600-V
• Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture
Features:
• Stranded, tinned copper conductors
• Highly flexible color coded insulation
Specifications:
• Size AWG: 18
• Conductor Stranding: 16/0.0100
• Nom. Jacket Thickness: 0.030 Inch
• Nom. Cable O.D. : 0.114 Inch
• Nom. Circular Mils: 1600
• Nom. MM2 : 10.3
• Part Number: NNCWUL18BL
