Type W Power Cable Pigtail Assemblies

Name: Type W Power Cable Pigtail Assemblies
Brand: Nassau National Cable
SKU: type-w-power-cable-pigtail-assemblies
Availability: InStock
Rating: 4.94 (7644 reviews)

Write a Review

Ask a Question Download PDF

SKU:

Select a Gauge

Type W Power Cable Pigtail Assemblies

Where are we? 4 Continents 8 Countries

Got any Questions?

Speak with a real person who will go out of their way to help you!

Call Us: 1-516-482-6313Text Us: 1-516-703-3460

Chat

Live Chat: Bottom Right Corner!

Email Us

info@nassaunationalcable.com

Quick Support

Product Name	Length	Price (Per FT.)	Action
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Bare End, 3ft Pigtail	Length /Qty	Price (Per FT.) $39.00 Available Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Bare End, 5ft Pigtail	Length /Qty	Price (Per FT.) $58.50 Available Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Bare End, 8ft Pigtail	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Bare End, 3ft Pigtail	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Bare End, 5ft Pigtail	Length /Qty	Price (Per FT.) $58.50 Available Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Bare End, 8ft Pigtail	Length /Qty	Price (Per FT.) $80.60 Available Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Lug, 3ft. Pigtail	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock $48.10 Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Lug, 5ft. Pigtail	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Male Cam-Lok and Lug, 8ft. Pigtail	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Lug, 3ft.	Length /Qty	Price (Per FT.) $48.10 Available Min: 1 FT Max: 1000000 FT	Action Color
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Lug, 5ft.	Length /Qty	Price (Per FT.) $79.60 Available Min: 1 FT Max: 1000000 FT	Action
Product Name 4/0 AWG 1C Type W Portable Round Power Cable Pigtail With Female Cam-Lok and Lug, 8ft.	Length /Qty	Price (Per FT.) Call 516-482-6313 for pricingOut Of Stock Min: 1 FT Max: 1000000 FT	Action Color

Product Information

Specification

Type W Power Cable Pigtail Assemblies

Applications:

Type W is a strong and versatile copper cable. Type W Portable Power Cable is suitable for use in industrial and mining applications as well as heavy-duty service and temporary as power supply. It is made of conductors which are stranded, hardened and insulated with superior insulation materials. They are also used for motor, battery and generator leads Mining Temporary Power ,Heavy Industrial, Ship to Shore Events, Generator Connections, Convention Centers

Also Known As:

Type W Cable Assemblies, Type W Portable Cable Assembly, Type W Generator Leads, Pigtail Assemblies, Type W Pigtail Assemblies, Type W Single Conductors Pigtail Assembly, Type W Pigtail Assembly 2000V.

Construction:

NEMA 3R while connected, Hard-use Chlorinated Polyethylene (CPE) rubber single-pass thermoset jacket, CPE provides greater abrasion and head resistance over, thermoplastic PPE/TPE jackets. Type W Industrial Grade Single conductor portable round power cable consists of an EPDM rubber inner and a CPE Jacket and 30 gauge flexible stranding. Oil and Sunlight Resistant. Single Conductors Listed as cULus. MSHA Approved. RoHS Compliant

Features/Standards:

• UL Listed
• UL 1650
• CSA C22.2 No. 96
• cULus
• Approved by Mine Safety Health Administration for use in mining applications. 07 KA150015-MHSA
• VW-1 • FT-1, FT-5
• -40°C + 90°C Dry
• 90°C Wet Rating
• RoHS Compliant
• Listed as Type RHH, RHW, & RHW-2 • MSHA 07-KA150015

*Data provided on this page is subject to change based on different manufacturers' variances

** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
