22/6C Stranded Riser Shielded PVC Security Alarm Cable 300V

22/6C Stranded Riser Shielded PVC Security Alarm Cable 300V

Description:

PVC insulated stranded bare copper conductors, twisted, aluminum mylar shielding with drain wire and an overall gray PVC jacket* with rip cord.

Also Know As:

22/6C Security Alarm Cable, 22/6C Riser Shielded Alarm Cable, 22/6C Riser Shielded Security Alarm Cable, 22/6C PVC Security Alarm Cable.

Application:

• Security Systems
• Intercom Systems
• Sound/Audio System
• Power-Limited Controls

Conductor: Bare Copper

Insulation:

• 22 AWG .007”
• 20 AWG .008”
• 18-16 AWG .010”
• 14-12 AWG .012”

Shield: Aluminum Mylar

Jacket: PVC

NEC Articles:

• 22-16 AWG: FPLR/760, CMR/800, CL3R/725
• 14-12 AWG: FPLR, CL3R

Voltage Rating: 300 V

Temp. Rating: -25C to 75C

Specification:

• Size: 22 AWG
• Conduuctors: 6
• Strands: Solid
• Part Number: 12206RSD
• CAP PF/FT: 53
• Outer Jacket Thickness: 0.015 Inches
• Nominal OD: 0.166 Inches
• Weight: 29 lbs/1000ft
