Collection: Aluminum Plex Cables

Suitable For Installation In Raceways, Channels, Conduits And Ducts, For Ambient Temperatures Down To -40°c, 1/0 Awg And Larger Are Rated For Cable Tray Use, And For Use In Accordance With National Electrical Code.

Applications:

Priority-plex Xhhw-2 Conductors Are Primarily Used For Power Distribution Where Light Weight And Flexibility Are Desired. Xhhw-2 600/1000 Volt Conductors May Be Used In Wet Or Dry Locations At Conductor Operating Temperatures Not Exceeding 90°c. Suitable For Installation In Raceways, Channels, Conduits And Ducts, For Ambient Temperatures Down To -40°c, 1/0 Awg And Larger Are Rated For Cable Tray Use, And For Use In Accordance With National Electrical Code.

Also Know as:

Priority Plex Cable, XHHW-2 Cable, Aluminum Priority Plex Wire, Raceways Cable, Priority Plex W/G Cable, XLPE Insulation Cable, 3C Aluminum Plex Cable, BOY Plex Cable.

Insulation:

Cross-linked polyethethylene (XLPE), solid colored, UL listed for sunlight resistant, -40°C.

Assembly:

Insulated phase conductors with slick jacket are plex’d with an insulated ground wire.
