Collection: Aluminum ACSR, AAC, AAAC, Solar Photovoltaic (PV)

About the Product

Aluminum Bare Transmission cables are essential for power distribution through primary and secondary power lines. Installed through overhead distribution channels, these cables are designed to withstand demanding outdoor conditions. Made from resilient 1350-H19 aluminum, some cables are left bare, while others have cross-linked polyethylene (XLPE) or high-density polyethylene (HDPE) insulation for additional protection. The key types of aluminum bare transmission cables include ACSR, AAC, and AAAC, each offering distinct advantages based on application needs.

Key Differences Between ACSR, AAC, and AAAC Cables

ACSR (Aluminum Conductor Steel Reinforced)

  • Composition: Steel core surrounded by aluminum strands, providing extra strength.
  • Best For: Long spans, high-tension power lines.
  • Strength: Highest tensile strength due to the steel core.
  • Flexibility: Less flexible than AAC and AAAC.

AAC (All Aluminum Conductor)

  • Composition: Entirely aluminum strands, no steel core.
  • Best For: Shorter spans and high-conductivity applications.
  • Strength: Lower tensile strength, ideal for urban distribution.
  • Flexibility: Very flexible and easy to handle.

AAAC (All Aluminum Alloy Conductor)

  • Composition: Aluminum alloy (6201-T81) for better strength and corrosion resistance.
  • Best For: Medium spans, corrosive environments.
  • Strength: Stronger than AAC, but not as strong as ACSR.
  • Flexibility: Balances flexibility and strength.

Standards and Approvals

ACSR Standards

  • ASTM B-230: Aluminum 1350-H19 wire for electrical purposes
  • ASTM B-232: Concentric laid aluminum conductors
  • ASTM B-498: Zinc galvanized steel wire for electrical purposes

AAC Standards

  • ASTM B-230: Aluminum 1350-H19 wire
  • ASTM B-231: Concentric lay stranded aluminum conductors

AAAC Standards

  • ASTM B-398: Aluminum alloy 6201-T81 conductors
  • ASTM B-399: Concentric lay stranded aluminum alloy conductors

Key Features

  • Conductor: 1350-H19 aluminum (AAC and ACSR) or 6201-T81 alloy (AAAC), offering lightweight, flexible installation.
  • Insulation: HDPE or XLPE for chemical and mechanical protection, enhancing service life.

Applications

  • ACSR: Long-distance transmission lines requiring extra strength.
  • AAC: Urban distribution prioritising flexibility and conductivity.
  • AAAC: Medium spans and environments prone to corrosion, such as coastal or industrial areas.
collection

  • ACSR – Aluminum Conductor Steel Reinforced Utility Wire
    ACSR – Aluminum Conductor Steel Reinforced Utility Wire
  • AAAC – All Aluminum Alloy 6201 Conductor Utility Wire
    AAAC – All Aluminum Alloy 6201 Conductor Utility Wire
  • AAC – All Aluminum Conductor Utility Wire
    AAC – All Aluminum Conductor Utility Wire
  • Aluminum Solar Photovoltaic 2KV PV Wire
    Aluminum Solar Photovoltaic 2KV PV Wire
