Copper Compression Bus Bar Connector Burndy YG14BTC28
Copper Compression Bus Bar Connector, 4/0 AWG - 1/0 AWG.
Description :
- Compression Busbar Connector
- Easier to use than Exothermic Connections
- Ideally suited for cellular tower applications.
• Features: BURNDYs YG14B2TC2C6C Compression Bus Bar Connector Is Ideally Suited For Cellular Tower Applicatons And Is Easier To Use Than Exothermic Connections, This High Conduc Tivity Wrought Copper Connector Allows Attachment Of The Ground Conductor To The Ground Bus With Just One Crimp Using The BURNDY Y750 HYPRESS Hydraulic Compression Tool And The U1105 Die Set, This Exclusive Patent Pending Design Allows The User To Attach #2 AWG Solid/Stranded And/Or #6 Solid/Stranded Copper Conductor To 1/4 Thick Copper Bus Bar, This Connection Is Suitable Using (1) Or (2) Conductors For Power, Grounding And Bonding Applictions, UL Listed To Both UL486 And UL467 (Suitable For Direct Burial) Ensures That This Connector Will Meet The Rigors Of Either Application, Prefilled With PENETROX E Compound And Strip Sealed, Tools, Die Set Catalog Number, And (number Of Crimps): Y750, PAT750 Tool, U1105 Die, (1)
Specifications :
| Application | For Direct Barial And Cellular Tower Applicatons And Is Easier To Use Than Exothermic Connections |
| Connector Type | Tap |
| EU RoHS Indicator | Yes |
| Material | Copper Alloy |
| Physical Attribute - Number of Crimps Required | 1 |
| Plated | N |
| Plating Type | Unplated |
| Prefilled Oxide Inhibitor | Y |
| Sub Brand | HYGROUND |
| Trade Name | HYGROUND® |
| Type | YG-B |
| UPC | 781810289273 |
| Dimension - B Length fraction | 64/79 in |
| Dimension - B Length inch | 0.81 in |
| Dimension - Bus Bar Size Tap Side inch | 4/0 AWG Str. to 1/0 AWG Str. Copper |
| Dimension - Pad Width inch | 1.50 in |
| Conductor - Copper Solid Run | 1/8" - 1/4" Busbar |
| Conductor - Copper Solid Tap | 4/0 AWG |
| Conductor - Copper Solid Tap Range | 4/0 AWG |
| Conductor - Copper Str Tap | 1/0 ;2/0 AWG;3/0 AWG;4/0 AWG |
| Conductor - Copper Str Tap Range | 1/0-4/0 |
| Conductor Type |
|
| Certification - CSA Approved | No |
| Certification - ETL | No |
| Certification - UL Listed Direct Burial | Yes |
| Certification - UL Recognized | No |
| Certification - cULus | Yes |
|
Industry Standard(s) |
|
| Standards - Industry Standards Met |
|
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
| Minimum Pack Quantity | 1 |
