Igus Connector RJ45 Phoenix Contact Bare Copper Shield TC Braid Harnessed CAT5e Cable

Also Known as:

Control Cable, CAT5e Cable, RJ45 Cable, Flexible Cable, IGUS Cable, Continues-Flex Cable, Dynamic Cable, Flexing Cable, Flex Cable, Linear Motion Cable

Construction:

• Conductor: Conductor consisting of bare copper wires (according to DIN EN 60228)

• Conductor Insulation: Mechanically high-quality TPE mixture (According to bus specification)

• Conductor Construction: According to bus specification

• Conductor Identification: white-green/green, white-orange/orange, white-blue/blue, white-brown/brown

• Overall Shield: Braid made of tinned copper wires. Shield about 60% optical.

• Outer Jacket: Low-adhesion mixture on the basis of PVC, adapted to suit the requirements in e-chains®.

• Jacket Color: Red lilac (similar to RAL 4001)

Properties and Approvals:

• Oil Resistance: No oil resistant
• Flame Retardant: According to IEC 60332-1-2, CEI 20-35, VW-1, FT-1
• Silicone-free: Free from silicon which can affect paint adhesion (according to PV 3.10.7 – status 1992).
• UL/CSA AWM: See data sheet for details
• EAC: Certified to no. TC RU C-DE. ME77.B.01559
• CTP: Certified to no. C-DE. PB49.B.00449
• Lead-free: Following 2011/65/EU (RoHS-II)
• CE: Following 2014/35/EU
