Colección: Type MC – Copper Conductors

About the Product

The metal clad cable is an electrical wire designed for use in direct burial applications, power and lighting circuits, and cable tray, among others. It is also allowed for use in both dry and wet locations not exceeding 90°C and 75°C respectively. The cable is armored with an aluminum interlocking strip, which offers great mechanical protection.

Conductors:

This aluminum armored cable has a stranded or solid copper conductor. Copper is the most common material used in electrical wires and cables, which is mostly because it has amazing electrical properties and is cheaper compared to other metals. The stranding enhances its flexibility and enables it to carry more current.

Also Known As:

Metal clad cable, aluminum armored cable, mc cable, mc wire, mc cable wiring, armored wire, armoured electrical cable, mc electrical wire, fire alarm mc cable, flexible armored cable, armored cable wiring, metal clad cable type mc, AIA Cable, armored fire alarm cable.

Armor:

Aluminum Interlocked Armor (AIA)


Standards:

  • Rated at 90°C wet or dry locations
  • Meets cold bend test at -25°C
  • UL Type MC
  • UL 44, UL 1569, UL 1581, UL 1685 (Flame Exposure Test)
  • ICEA S-95-658 NEMA WC70
  • ICEA T-29-520 210,000 BTU Flame Test
  • IEEE 1202/CSA FT4 70,000 BTU Flame Test
  • IEEE 383/UL1581 70,000 BTU Flame Test

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.


  • Metal Clad Stranded / Solid MC Copper Conductor W/G Aluminum Armored Cable 600V
    Metal Clad Stranded / Solid MC Copper Conductor W/G Aluminum Armored Cable 600V
  • Type MC Metal Clad Aluminum Interlocked Armor AIA PVC Jacketed Copper Feeder Conductor
    Type MC Metal Clad Aluminum Interlocked Armor AIA PVC Jacketed Copper Feeder Conductor
  • Metal Clad Solid / Stranded Copper Conductor Aluminum Armored W/ Ground PVC Jacket
    Metal Clad Solid / Stranded Copper Conductor Aluminum Armored W/ Ground PVC Jacket
  • Type MC W/G Aluminum interlocked Armor AIA Copper Conductor Metal Clad PVC Jacket Control Cable
    Type MC W/G Aluminum interlocked Armor AIA Copper Conductor Metal Clad PVC Jacket Control Cable
  • Type MC Color Code 277/480V
    Type MC Color Code 277/480V
  • Type MC W/G Aluminum interlocked Armor AIA Copper Conductor Metal Clad PVC Jacket Power Cable
    Type MC W/G Aluminum interlocked Armor AIA Copper Conductor Metal Clad PVC Jacket Power Cable
  • Duraclad Copper with AL Ground Lightweight Steel Type AC Armor Cable 600V
    Duraclad Copper with AL Ground Lightweight Steel Type AC Armor Cable 600V
